Elitech SVP-DC Smart Cordless Vacuum Pump A2L Compatible , 2-Stage HVAC Vacuum Pump, 1 L/s Pumping Rate, 2Pa Extreme Pressure, for HVAC/R
Intelligent wireless control
Remote operation via APP (compatible with iOS/Android), 5 working modes free switching, real-time generation of vacuum curve, task progress at a glance
High-Efficiency Brushless Motor
Dual-stage rotary vane design with 180W brushless motor, delivering 1 L/s (2 CFM) pumping speed and an ultimate vacuum of 2Pa (15 microns) for fast, professional-grade performance.
Long Battery Life
The 450mAh rechargeable lithium battery supports up to 60 hours of low-power usage, with an auto-shutoff feature (15/30/60 minutes selectable) to help save battery life.
Durable and Eco-Friendly Design
With an IP54 waterproof rating and a wide operating temperature range of -10 to 50°C, the device remains stable even in harsh environments. It also supports ice water calibration (0°C) to ensure long-term accuracy.
Easy Maintenance & Durable Build
Quick oil change system (260mL capacity), leak-proof 1/4" SAE fittings, and IP-rated protection. Operates in 5°C~40°C (41°F~104°F) environments.
Mode: SVP-DC series
Stage: 2 Stages
Rated power supply: 18V DC
Pumping rate: 1L/s, 2 CFM
Extreme pressure: 2Pa /15 Microns
Motor power: 180W, 1/4 Hp
Motor type: Brushless motor
Speed regulation: 1000-3500 RPM
Fuel Volume: 260 mL
Usage environment: 5℃~40℃/41°F~104°F
Wireless distance: 30m
Built in vacuum gauge: 1000-65000 Pa ±5%
External dimensions: 325*117*166 mm
Weight: 4.7Kg
Air Inlet: 1/4 SAE
Power Battery
Mode: MT-BL 1850
Battery parameters: 18V 5AH
Discharge capability: 2.5C
Product Information
Product Information
Shipping & Returns
Shipping & Returns
Elitech SVP-DC Smart Cordless Vacuum Pump A2L Compatible , 2-Stage HVAC Vacuum Pump, 1 L/s Pumping Rate, 2Pa Extreme Pressure, for HVAC/R
Elitech SVP-DC Smart Cordless Vacuum Pump A2L Compatible , 2-Stage HVAC Vacuum Pump, 1 L/s Pumping Rate, 2Pa Extreme Pressure, for HVAC/R
Intelligent wireless control
Remote operation via APP (compatible with iOS/Android), 5 working modes free switching, real-time generation of vacuum curve, task progress at a glance
High-Efficiency Brushless Motor
Dual-stage rotary vane design with 180W brushless motor, delivering 1 L/s (2 CFM) pumping speed and an ultimate vacuum of 2Pa (15 microns) for fast, professional-grade performance.
Long Battery Life
The 450mAh rechargeable lithium battery supports up to 60 hours of low-power usage, with an auto-shutoff feature (15/30/60 minutes selectable) to help save battery life.
Durable and Eco-Friendly Design
With an IP54 waterproof rating and a wide operating temperature range of -10 to 50°C, the device remains stable even in harsh environments. It also supports ice water calibration (0°C) to ensure long-term accuracy.
Easy Maintenance & Durable Build
Quick oil change system (260mL capacity), leak-proof 1/4" SAE fittings, and IP-rated protection. Operates in 5°C~40°C (41°F~104°F) environments.
Mode: SVP-DC series
Stage: 2 Stages
Rated power supply: 18V DC
Pumping rate: 1L/s, 2 CFM
Extreme pressure: 2Pa /15 Microns
Motor power: 180W, 1/4 Hp
Motor type: Brushless motor
Speed regulation: 1000-3500 RPM
Fuel Volume: 260 mL
Usage environment: 5℃~40℃/41°F~104°F
Wireless distance: 30m
Built in vacuum gauge: 1000-65000 Pa ±5%
External dimensions: 325*117*166 mm
Weight: 4.7Kg
Air Inlet: 1/4 SAE
Power Battery
Mode: MT-BL 1850
Battery parameters: 18V 5AH
Discharge capability: 2.5C
Original: $1,096.59
-65%$1,096.59
$383.81Product Information
Product Information
Shipping & Returns
Shipping & Returns
Description
Intelligent wireless control
Remote operation via APP (compatible with iOS/Android), 5 working modes free switching, real-time generation of vacuum curve, task progress at a glance
High-Efficiency Brushless Motor
Dual-stage rotary vane design with 180W brushless motor, delivering 1 L/s (2 CFM) pumping speed and an ultimate vacuum of 2Pa (15 microns) for fast, professional-grade performance.
Long Battery Life
The 450mAh rechargeable lithium battery supports up to 60 hours of low-power usage, with an auto-shutoff feature (15/30/60 minutes selectable) to help save battery life.
Durable and Eco-Friendly Design
With an IP54 waterproof rating and a wide operating temperature range of -10 to 50°C, the device remains stable even in harsh environments. It also supports ice water calibration (0°C) to ensure long-term accuracy.
Easy Maintenance & Durable Build
Quick oil change system (260mL capacity), leak-proof 1/4" SAE fittings, and IP-rated protection. Operates in 5°C~40°C (41°F~104°F) environments.
Mode: SVP-DC series
Stage: 2 Stages
Rated power supply: 18V DC
Pumping rate: 1L/s, 2 CFM
Extreme pressure: 2Pa /15 Microns
Motor power: 180W, 1/4 Hp
Motor type: Brushless motor
Speed regulation: 1000-3500 RPM
Fuel Volume: 260 mL
Usage environment: 5℃~40℃/41°F~104°F
Wireless distance: 30m
Built in vacuum gauge: 1000-65000 Pa ±5%
External dimensions: 325*117*166 mm
Weight: 4.7Kg
Air Inlet: 1/4 SAE
Power Battery
Mode: MT-BL 1850
Battery parameters: 18V 5AH
Discharge capability: 2.5C
